Sample System Configuration Diagrams
Below are six example circuit diagrams detailing the required
parameter values for Multi Temperature Set Point (MTSP)
and Single Temperature Set Point (STSP) system
configurations.
Please Note:
All MTSP circuit diagrams have:
“ID92:1” - MTSP configuration ENABLED
“ID15” - Heating Common Zone DISABLED
“ID01” - Cooling Common Zone DISABLED
“ID105:1” - Heating Fan Scaling ENABLED
“ID111:1” - Cooling Fan Scaling ENABLED
“ID93:1” - Cooling Constant Zone ENABLED (‘1’ = Zone A)
All STSP circuit diagrams have:
“ID92:0” - STSP configuration ENABLED
“ID15:1” - Heating Common Zone ENABLED
“ID01:1” - Cooling Common zone ENABLED
“ID105:1” - Heating Fan Scaling ENABLED
“ID111:1” - Cooling Fan Scaling ENABLED
“ID93” - Cooling Constant Zone DISABLED
Table 10: Sample Circuit Diagrams Reference
NO. OF ZONES HEATING ONLY DUAL COMFORT
2 Page 26 Page 29
3
Page 27 Page 30
4
Page 28 Page 31
