Brivis ZonePlus B061006 User Manual

4
Application
ZonePlus may be used on the following Brivis Ducted
Systems:
• Brivis StarPro Ducted Gas Heaters produced after 20 May 2013
(serial number greater than 995000)
• Brivis Dual Comfort Systems (Brivis StarPro Heaters and ICE
Refrigerated Cooling)
• Brivis StarPro Ducted Gas Heaters and Brivis Evaporative Cooling
• Zoning is not available during Evaporative Cooling mode
• The NC-6 Master Controller, or any other ZonePlus NC-6,
where fitted, will operate a Brivis Evaporative cooler with all
normal features and functionality
1.0 INTRODUCTION
Brivis ZonePlus brings the possibility of total comfort control to occupants
by providing the precise amount of heating or cooling into each space, or
zone, within a home.
A zoning system is a heating and/or cooling control system that
maintains each zone at a predetermined temperature set point.
ZonePlus can control up to four independent zones.
Brivis ZonePlus design objectives are to:
• direct conditioned air based on the individual needs of each zone
• keep the sound produced by the system low enough that occupants
do not find it objectionable
• seamlessly interface with and protect the Brivis heating and cooling
climate system
• maintain the minimum airflow necessary to keep the heating and
cooling equipment running efficiently
2.0 ZONE CONTROL SYSTEM
It’s important to keep in mind what a zoned system can and cannot do.
A zone control system is only part of a complete heating and cooling
system. A properly selected heating and/or cooling system has a
defined heating and cooling capacity, so it is important to specify the
system’s capabilities. In particular, how many zones can be operated
individually or simultaneously in both heating or cooling modes at specific
design conditions.
When designing a zoned home comfort system, there are two
primary considerations, dependent on the needs and
requirements of the home owners.
1. system designed primarily for energy savings – used
primarily to shut off unoccupied zones
2. system designed primarily for comfort – used primarily to
control temperatures in diverse zones
Both applications can be either Multi Temperature Set Point or
Single Temperature Set Point.
Note:
ZonePlus systems should only be installed by
authorised Brivis Dealers who have successfully completed
the Brivis ZonePlus Training Module.
Note:
All system configuration and parameter settings shall be
recorded in the Appendix (Table 7 & Table 8) of this manual
and retained by home owner for future reference.
