Diagram 1b. NC-6 and NT-1 – Physical Characteristics
Description
1
Slot for wall mounting screw
2
Front face retaining clip
3
Slot for 2-wire bus cable
4
2-wire bus terminal block (TW1 & TW2)
5
NT-1 Sensor LED
5
1
1
2
2
3
4
1
1
2
2
3
4
