Brivis ZonePlus B061006 - NC-6 Networker Interface; Diagram 1 a. NC-6 Networker - Key Functions

2
Diagram 1a. NC-6 Networker – Key Functions
* Active
with MTSP systems only
** Active with STSP systems only
Mode
(Heating / Cooling)
Advance Period
Auto Program
or Manual
On / Off
Zone Key*
Mode
Selected
Zone Selected*
Set Temperature Room (zone) Temperature
Rotary Dial
Select
Set Temp
Marker
Fan
Symbol
Day
Auto Program
or Manual
Digital
Clock
Zone Keys**
Flame
Symbol
