Definitions
Zone
One room or a group of rooms, normally selected on the basis of usage
or that have similar heating or cooling needs.
Controlled Zone
A zone that is separately controlled by its own zone sensor and zone
damper. There are as many zone sensors in the home comfort system
as there are Controlled Zones.
Common Zone
A zone that is not separately controlled by its own sensor and zone
damper. It operates whenever heating or air conditioning is on.
Constant Zone
A predetermined zone, typically the largest and containing the return air,
is designated the Constant Zone and functions as a Common Zone
only during refrigerated cooling mode to ensure the minimum cooling
airflow requirements are met. The system minimum cooling airflow is
designated as 75% of the maximum system cooling airflow setting.
Multi Temperature Set Point (MTSP) ZonePlus System
The zone temperature set point can be set independently across all
Networkers and/or Temperature Sensors.
Single Temperature Set Point (STSP) ZonePlus System
The zone temperature set point is the same across all Networkers and/or
Temperature Sensors.
Fan Scaling
Brivis ZonePlus allows the system fan speed for each zone to
be individually set. HEATING and COOLING fan speeds can
both be set in the range of 1 – 16 (Min – Max).
Brivis NC-6 Networker Controller
Primary user interface with LCD display. Where multiple NC-6s are
installed, the “Master” Networker Controller can be identified by the
word “Clock” displayed adjacent to Key “5” when system is OFF. The
Master has default sensor identification “n01”.
Brivis NT-1 Remote Temperature Sensor
Zone temperature sensor with LED that blinks during communication
with Master NC-6. Default NT-1 sensor identification is “n02”.
Additional NC-6 Networkers can be used in place of up to 3x NT-1
sensors.
Sensor
Both the NC-6 and NT-1 function as zone (room) temperature sensors
– in this context, the word “sensor” in this manual can apply to both.
Adaptive Zoning (non-ZonePlus Control System)
One Brivis Networker Controller with zones, the ON and OFF times of
which are controlled by the Networker.
The minimum and maximum HEATING fan speeds are set during
commissioning and this range is divided into equal segments depending
upon the number of zones. Only maximum REFRIGERATED
COOLING fan speed can be set and is fixed during operation.
Adaptive Zoning is not covered in this manual. Please refer to the
Brivis StarPro Heater Installer Manual for more information.
