Brivis ZonePlus B061006 User Manual

i
Brivis ZonePlus 4-Zone Control Kit
Scope
This manual is intended to be used as a guide to the design,
installation and commissioning of Brivis ZonePlus, a Zoning Control
System for Brivis Ducted Heating and Cooling equipment. For the
installation of Brivis Heating and Integrated Cooling products
please refer to the equipment Installer Manuals. This manual is
based on Australian Standards - for all other applications, please refer to
relevant local codes and regulations.
Any deviations from these instructions may, at the discretion of Brivis,
void the warranty. As a result, the customer and/or installer may be
charged a fee for non-product warranty related call outs. Also, note
that failure to comply with these instructions may preclude Brivis from
being able to service the product.
Terminology:
Shall: Indicates a mandatory requirement of this manual.
Should: Indicates a recommended requirement of this manual.
Disclaimer
IMPORTANT NOTICE: This document is a guide only. Laws, regulations and industry
standards can vary between States and Territories. Accordingly, this guide must be read in
conjunction with, and subject to, all laws, regulations and industry standards applicable in the
State or Territory in which the products are installed. You must ensure that the installation of
the products will comply with those laws, regulations and standards, and that the
products recommended to customers are fit for the purpose for which they are intended.
Specifications subject to change without notice.
© Brivis Climate Systems Pty Ltd 2013
Table 1: Contents of ZonePlus Kit - Brivis Part No. B061006
Brivis Part No. Description Qty
B022890 NC-6 Networker 1
B024891
NT-1 Remote Temperature
Sensor
3
B061016 ZonePlus Installer’s Manual 1
B061017 ZonePlus Owner’s Manual 1
Optional Brivis Accessories (not supplied)
B024892 N-PM1 Power Module
B023178 516 Zone Module
Refer to Table 2 (p.6) – System Configuration &
Accessory Summary for more information
Inspect the product to ensure it matches your order. In the
event of damage or incorrect delivery, notify supplier
immediately. Brivis accepts no responsibility for
installation of damaged or incorrect product.
Please read these installation instructions before
undertaking the installation process.
Note:
Zone Dampers are not supplied.

Brivis ZonePlus B061006 Specifications

General

Brand	Brivis
Model	ZonePlus B061006
Category	Controller
Language	English
