Broadcom MegaRAID and HBA Tri-Mode Storage Adapter
Characteristics
This chapter presents the physical characteristics of each board, including the board size and the connector locations.
MegaRAID 9670W-16i Adapter – Connector and LED Designations
The adapter is a 167.52 (±0.13) mm × 111.15 (±0.13) mm board. The component height on the top and bottom of the
adapter complies with the PCIe specification.
The following figure shows the connectors and LED locations on the adapter. Pin 1 on the headers and connectors is
highlighted in red in the figure.
Figure 5: Card Layout for the MegaRAID 9670W-16i Tri-Mode Storage Adapter
J7
J14
LED5
J8
J17
J18
J10
J11
J2
J4
LED2
LED3
LED6
The following table describes the headers and connectors on the adapter.
Broadcom 96xx-MR-HBA-Tri-Mode-UG108
31
