Broadcom 96xx User Guide
Broadcom
®
96xx PCIe 4.0, 24G SAS MegaRAID
™
and eHBA Tri-Mode Storage Adapters
Revision History
Version 2.4, January 17, 2024
Added FCC Compliance.
Version 2.3, October 31, 2023
•
Updated the address to 0x4C in Virtual Pin Port Management.
•
Removed reference to LED4.
Version 2.2, September 27, 2023
Updated the 9670-24i adapter connector-to-CSW port associations in Tri-Mode Storage Interface and PCIe (NVMe)
Support.
Version 2.1, August 1, 2023
•
Updated the adapter dimensions in Broadcom MegaRAID and HBA Tri-Mode Storage Adapter Characteristics.
•
Updated External Adapter Connector Pinout.
Version 2.0, August 30, 2022
•
Updated the resistor values in Sideband Signals.
•
Revised Typical Power values in MegaRAID Tri-Mode Storage Adapter Power Supply Requirements and eHBA Tri-
Mode Storage Adapter Power Supply Requirements.
•
Changed SFF-8644 instances to SFF-8674.
Preliminary, Version 1.1, June 13, 2022
•
Revised the NVMe SSD count in MegaRAID 9670W-16i, 9670-24i, and 9660-16i Adapter RAID Features.
•
Updated the 05-60006-00 description in Storage Interface Cabling.
•
Added Overtemperature Behavior.
•
Updated the Adapter Marks and Certifications table in Marks, Certifications, and Compliance.
•
Added the eHBA 9600-8i8e adapter.
•
Renamed HBA to eHBA.
Preliminary, Version 1.0, March 8, 2022
•
Updated the 9670-24i and 9600-24i adapters in the NVMe Device or PCIe Switch Direct-Attach Options Supported for
Each Adapter table in PCIe (NVMe) Support.
•
Updated the following tables in PCIe (NVMe) Support:
–
9670-24i Adapter PCIe Topology Configuration Combinations
–
9600-24i Adapter PCIe Topology Configuration Combinations
•
Updated External Adapter Connector Pinout.
•
Added board layout images.
•
Updated Tri-Mode Storage Adapter Power Supply Requirements.
•
Updated the values regarding the CacheVault power module in MegaRAID Tri-Mode Storage Adapter Power Supply
Requirements.
