Broadcom 96 Series User Manual

Broadcom 96xx User Guide Broadcom
®
96xx PCIe 4.0, 24G SAS MegaRAID
™
and eHBA Tri-Mode Storage Adapters
Table 2: eHBA Tri-Mode Storage Adapter Features
Adapter 9600-24i 9600-16i 9600-8i8e 9600W-16e 9600-16e
Ports 24 internal 16 internal 8 internal
8 external
16 external 16 external
I/O Processor SAS4024 SAS4016 SAS4016 SAS4016W SAS4016W
Host Interface x8 PCIe 4.0 x8 PCIe 4.0 x8 PCIe 4.0 x16 PCIe 4.0 x8 PCIe 4.0
Form Factor LP-MD2 LP-MD2 LP-MD2 LP-MD2 LP-MD2
Storage Interface SAS, SATA, and
PCIe (NVMe)
SAS, SATA, and
PCIe (NVMe)
SAS, SATA, and
PCIe (NVMe)
SAS, SATA,
and PCIe
SAS, SATA,
and PCIe
Storage Interface
Connectors
Three SFF-8654 x8 Two SFF-8654 x8 One SFF-8654 x8
Two SFF-8674 x4
Four SFF-8674 x4 Four SFF-8674 x4
Broadcom 96xx-MR-HBA-Tri-Mode-UG108
6

Broadcom 96 Series Specifications

General
