Brocade FastIron WS Hardware Installation Guide 51
53-1002188-01
Hardware specifications for FastIron WS models
5
DRAFT: BROCADE CONFIDENTIAL
Power cords
All of the FastIron WS devices ship with US-compatible power cords unless otherwise specified at
the time of order. United Kingdom- and European-compatible power cords are also available.
AC power supply specifications
The FastIron WS switches include an integrated AC power supply:
• standard IEC type (IEC320) input connector
• operating 90 VAC to 264 VAC input, universal/wide input
1000Base-SX MMF LC connector for SFP
module
62.5/125 200 .5 – 275
MMF 62.5/125 500 .5 – 550
MMF 50/125 900 .5 – 595
MMF 50/125 1500 .5 – 740
MMF 50/125 2000 .5 – 860
1000Base-SX 2 MMF LC connector for SFP
module
62.5 500 up to 2000
(2 km)
1000Base-T Copper RJ-45 jack for
standard unshielded
twisted pair (UTP or
Category 5)
n/a n/a up to 100 meters
100Base-BX
100Bse-BX-D
SMF LC connector for SFP
module
9 1310/1490 10000 (10 km)
100Base-FX MMF LC connector for SFP
module
62.5 500 up to 2000
(2 km)
100Base-FX-IR MMF SC 62.5 125 2 km (1.24 miles)
100Base-FX-LR SMF SC 9 125 20 km
(12.43 miles)
100Base-TX Copper RJ-45 jack for
standard unshielded
twisted pair (UTP or
Category 5)
n/a n/a up to 100 meters
10Base-TX Copper RJ-45 jack for
standard unshielded
twisted pair (UTP or
Category 5)
n/a n/a up to 100 meters
TABLE 20 Cable length summary table (Continued)
Cable type Connector type Core diameter
(microns)
Modal bandwidth
(MHz*km) or
wavelength (nm)
Range (meters)
