IC-40 LUBRICATION SCHEDULE
LUBRICATION INTERVALS
ITEM DESCRIPTION
LUBE
50 250 500 1000 MONTHS NOTES
HOUR HOUR HOUR HOUR
1 Accelerator Linkage SIL X 2 Points (Not on E.F.I.)
2 Anti-Two-Block Arm SIL X 2 Points
3 Axle Differential UTF X 12 Check @50, Change @12 Mo.*
4 Axle Kingpins MPG X 8 Zerks
5 Axle Pivot Pin MPG X 2 Zerks
6 Axle Planetary Hubs 424 X 12 Check @50, Change @12 Mo.*
7 Boom Extension Pins MPG X 6 Pins - Wipe
8 Boom Rub Pads SIL X Spray or Wipe
9 Brakes HO X 12 Check @50, Change @12 Mo.*
10 Control Valve Links SIL X 12 Points
11 Drive Shaft, Pump MPG X 2 Zerks
12 Drive Shaft, Motor MPG X 4 Zerks
13 Engine Oil EO X X 6 Max. Check Daily, Change @250
Hrs. or 6 Mo. Max.
14 Hook Swivel & Pin MPG X Wipe
15 Hydraulic Oil HO X X 12 Max. Check Daily, Change @1000
Hours or 12 Mo. Max.
16 Outrigger Legs SIL X Wipe Upper & Lower Sides
17 Pedal Hinges SIL X 2 Points
18 Rotation Bearing MPG X 1 Zerk*
19 Rotation Gearbox MPL X 12 Check @250, Change @12 Mo.
20 Rotation Gear Teeth OGG X Brush On*
21 Rotation Pinion Bearing MPG X 1 Zerk
22 Sheave Block MPG X 2 Zerks
23 Sheave Pins MPG X 1 Zerk Std, 1 On Boom Ext.
24 Steering Cylinder Ends MPG X 4 Zerks
25 Steering Tie rod End MPG X 4 Zerks
26 Winch(es) MPL X 12 Check @250, Change @12 Mo.
27 Wire Rope 2-X X Spray, Brush or Soak*
28 Wire Rope Retainers SIL X
* See Procedures in the Manual
LUBE SYMBOLS
FLUID VOLUMES
HO - Approved Hydraulic Fluids Axle Differential - 3 Gal. each
EO - Engine Oil - See Specs in Engine Manual Axle Hubs - 1.5 Pts. each
MPG - Multi-Purpose Gun Grease Brake Reservoir - 1 Pt.
MPL - Multi-Purpose Gear Lube - SAE 80W-90 Engine Coolant - 3 Gal.
OGG - Open Gear Grease, Such as Mobilkote S Eng. Oil (Nissan) - 1 Gal.
SIL - Silicone Lube - Aerosol with Concentrating Tube Fuel Tank - 13.5 Gal.
2-X - AMOVIS #2-x Hoist - 2 Pts.
UTF - D-A Lube Hydratrans 135 Hyd Tank - 14 Gal.
DTE - D-A Lube Hydrasafe HiVi ISO 15 3-9 Winch, Aux. Frnt - 8 Oz. each
