Brookeld Engineering Laboratories, Inc. Page 43 Manual No. M14-023
SPINDLE ENTRY CODE SMC SRC
T-C 93 100 0
T-D 94 200 0
T-E 95 500 0
T-F 96 1000 0
ULA 00 0.64 1.223
HT-DIN-81 81 3.7 1.29
SC4-DIN-82 82 3.75 1.29
SC4-DIN-83 83 12.09 1.29
DIN-85 85 1.22 1.29
DIN-86 86 3.65 1.29
DIN-87 87 12.13 1.29
SC4-14 14 125 0.4
SC4-15 15 50 0.48
SC4-16 16 128 0.29
SC4-18 18 3.2 1.32
SC4-21 21 5 0.93
SC4-25 25 512 0.22
SC4-27 27 25 0.34
SC4-28 28 50 0.28
SC4-29 29 100 0.25
SC4-31 31 32 0.34
SC4-34 34 64 0.28
CP-40 / CPE-40 / CPA-40Z 40 0.327 7.5
CP-41 / CPE-41 / CPA-41Z 41 1.228 2
CP-42 / CPE-42 / CPA-42Z 42 0.64 3.84
CP-51 / CPE-51 / CPA-51Z 51 5.178 3.84
CP-52 / CPE-52 / CPA-52Z 52 9.922 2
V-71 71 2.62 0
V-72 72 11.1 0
V-73 73 53.5 0
V-74 74 543 0
V-75 75 213 0
Table D-1
(Continued from previous page)
Table D-2 lists the model codes and spring torque constants for each viscometer model.
