Brookeld Engineering Laboratories, Inc. Page 6 Manual No. M14-023
e equivalent units of measurement in the SI system are calculated using the following conversions:
SI CGS
Viscosity: 1 mPa•s = 1 cP
Torque: 1 Newton•m = 10
7
dyne•cm
References to viscosity throughout this manual are done in CGS units. e DV1 Viscometer provides
equivalent information in SI units.
I.1 Components
COMPONENT PART NUMBER QUANTITY
DV1
varies 1
Model G Laboratory Stand Model G 1
Spindle Set with Case* varies 1
DV1MLV set of four spindles (#61 through #64) SSL or SSLK
†
DV1MRV set of six spindles (#02 through #07) SSR or SSRK
†
DV1MHA/HB set of six spindles (#02 through #07) SSH or SSHK
†
Shipping Cap* B-30-3Y 1
Power Cord (115V/230V) DVP-65/66 1
Guardleg* ( not supplied with HA/HB versions) varies 1
DV1MLV B-20Y or B20KY
†
DV1MRV B-21Y or B21KY
†
Carrying Case DVE-106 1
Operating Manual M14-023 1
For cone/plate versions:
Spindle wrench CP-23 1
Cone spindle CPA-XXZ 1
Sample cup varies 1
Standard CPA-44YZ
With embedded temperature probe and cable CPA-44PYZ
e following applies to DV1 Viscometers with the temperature probe option. Look for the symbol
Tp
throughout this manual for instructions pertaining specically to DV1 Viscometers with
temperature probe option.
OPTIONAL ITEMS
RTD Temperature Probe
DVP-94Y 1
Probe Clip DVE-50A 1
RTD Cable when supplied with Cone/Plate version SC4-61Y 1
Please check to be sure that you have received all components and that there is no damage. If you are
missing any parts, please notify Brookeld Engineering or your local Brookeld agent immediately.
Any shipping damage must be reported to the carrier.
* Not supplied with Cone/Plate version.
†
“K” in the part number identies EZ-Lock spindles.

Brookfield DV1 Specifications

General

Speed Range	0.3 to 100 rpm
Display	LCD
Number of Speeds	18
Power Supply	100-240 VAC, 50/60 Hz
Viscosity Range	1 to 2, 000, 000 cP
Temperature Measurement	Optional
Accuracy	±1% of full scale range
Repeatability	+/- 0.2%
