Brookfield DV1 User Manual

Brookeld Engineering Laboratories, Inc. Page 42 Manual No. M14-023
Appendix D - Spindle Entry Codes and SMC/SRC Values
When using a standard Brookeld digital Viscometer or Rheometer, each spindle has a two digit
entry code which is entered via the keypad on the DV1. e entry code allows the DV1 to calculate
Viscosity, Shear Rate and Shear Stress values and can also be calculated when using coaxial cylinder
geometry (SSA, ULA, ermosel, DAA, etc.) and cone/plate geometry.
Each spindle has two constants which are used in these calculations. e Spindle Multiplier Constant
(SMC) used for viscosity and shear stress calculations, and the Shear Rate Constant (SRC), used
for shear rate and shear stress calculations. Note that where SRC = 0, no shear rate/shear stress
calculations are done and the data displayed is zero (0) for these functions.
Table D-1
(Continued on following page)
SPINDLE ENTRY CODE SMC SRC
RV1 01 1 0
RV2 02 4 0
RV3 03 10 0
RV4 04 20 0
RV5 05 40 0
RV6 06 100 0
RV7 07 400 0
HA1 01 1 0
HA2 02 4 0
HA3 03 10 0
HA4 04 20 0
HA5 05 40 0
HA6 06 100 0
HA7 07 400 0
HB1 01 1 0
HB2 02 4 0
HB3 03 10 0
HB4 04 20 0
HB5 05 40 0
HB6 06 100 0
HB7 07 400 0
LV1 61 6.4 0
LV2 62 32 0
LV3 63 128 0
LV4 or 4B2 64 640 0
LV5 65 1280 0
LV-2C 66 32 0.212
LV-3C 67 128 0.210
Spiral 70 105 0.677
T-A 91 20 0
T-B 92 40 0

Brookfield DV1 Specifications

General

Speed Range	0.3 to 100 rpm
Display	LCD
Number of Speeds	18
Power Supply	100-240 VAC, 50/60 Hz
Viscosity Range	1 to 2, 000, 000 cP
Temperature Measurement	Optional
Accuracy	±1% of full scale range
Repeatability	+/- 0.2%
