Installation and Operation Manual
X-TMF-5800S-MFC-eng
PN 541-C-051-AAG
November, 2008
Models 5800-S
18
Table 2-3: Electrical interfacing. Smart TMF cable
sub D (25p)
female
pin no.
sub D (9p)
female
pin no.
1. 6 brown Setpoint return (-)
2. 10 white 0 (1)-5 Vdc Flow signal output
3. 9 grey/pink (TTL) Open collector alarm output
4. 2 red/blue 0 (4)-20 mA Flow signal output
5. 13 red +15 Vcc to +28 Vdc Power supply
6. 14 blue -15 Vdc Power supply (if required)
7. 3 violet 0 (4)-20 mA Setpiont input (+)
8. 5 grey 0 (1)-5 Vdc Setpiont input (+)
9. 12 7 5 black Power supply common
10. 8 pink Flow signal output common
11. 4 yellow +5 Vdc ref. output
12. 7 green valve override input
11 shielding Chassis
14. 2 3 green/white Optional RS232C-RxD or RS485-A-
15. 3 2 blue/white Optional RS232C-TxD or RS485-A+
Read-out side
sub D (15p)
male
pin no.
Sub-D (15 c.)
sub D (15p)
female
pin no.
Colour Function Computer side
Section 2: Installation
