Brother DCP-7060D Service Manual

1-1
Confidential
1. SPECIFICATIONS LIST
1.1 General
Specifications are subject to change without notice.
Model
DCP-7055
DCP-7057
DCP-7057E
DCP-7055W
DCP-7057W
DCP-7060D DCP-7065DN
DCP-7070DW
HL-2280DW
Print method Electrophotographic / Laser
Resolution 600 dpi x 600 dpi, HQ1200 (2400 X 600 dpi) quality
Print speed Up to 20/21 ppm Up to 24/24
ppm
Up to 26/27 ppm
* When loading A4 or Letter-size paper from the paper tray.
Warm-up time From Sleep Mode: Less than 7 seconds
* At 23°C (73.4F)
From Power OFF → ON: Less than 27 seconds From Power
OFF → ON:
Less than
28 seconds
* At 23°C (73.4F)
First print
time
From Ready
mode
Less than 10.0 seconds Less than 8.5 seconds
From Sleep
mode
Less than 19.0 seconds Less than 16.5 seconds
CPU ARM9 200MHz
Memory 16 MB 32 MB
Backup Clock
N/A
Interface Hi-Speed
USB 2.0
Hi-Speed USB
2.0,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Hi-Speed
USB 2.0
Hi-Speed
USB 2.0,
Ethernet 10/
100 BASE-
TX
Hi-Speed USB
2.0, Ethernet
10/100 BASE-
TX,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Power
Consumption
* Measured
with only
USB
connected
Peak 1080 W
Copying Average: Approximately 445 W
Ready Average: Approximately 55 W
Sleep,
Wireless
LAN: ON
N/A Average:
Approximately
2.8 W
N/A Average:
Approximately
2.8 W
Deep Sleep Average:
Approximately
0.9 W
Average:
Approximately
1.0 W
Average: Approximately
0.9 W
Average:
Approximately
1.0 W

Brother DCP-7060D Specifications

General

Dimensions (WxDxH)	405 x 399 x 268 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Digital sender	No
Maximum duty cycle	- pages per month
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, Image, OCR
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	2.63 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Processor family	ARM
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
AC input frequency	50 - 60 Hz
Power consumption (standby)	55 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	445 W
Sustainability certificates	ENERGY STAR
Package weight	13.200 g
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
