Brother DCP-7060D Service Manual

1-9
Confidential
1.5 Paper
1.5.1 Paper handling
Specifications are subject to change without notice.
1.5.2 Media specifications
Specifications are subject to change without notice.
Model All models
Paper Input Manual feed slot 1 sheet
Paper tray 250 sheets
ADF (Only for
ADF models)
35 sheets
Paper Output Face-down 100 sheets
Face-up 1 sheet (straight paper path)
Auto Duplex
(Only for Duplex models)
Yes
Model All models
Media type Paper tray Plain paper, Thin paper, Recycled Paper
Manual feed slot Plain paper, Thin paper, Thick paper, Recycled paper,
Bond paper, Labels, Envelope (Thin & Thick)
Duplex
(Only for duplex
printing models)
Plain paper, Recycled paper
ADF (Only for
ADF models)
Plain paper, Recycled paper
Media weight Paper tray 60 to 105 g/m
2
(16 to 28lb)
Manual feed slot 60 to 163 g/m
2
(16 to 43lb)
Duplex
(Only for duplex
printing models)
60 to 105 g/m
2
(16 to 28lb)
ADF (Only for
ADF models)
64 to 90 g/m
2
(17 to 24lb)
Media size Paper tray A4, Letter, B5 (ISO/JIS), A5, A5 (Long Edge), B6 (ISO), A6,
Executive, Legal
*1
, Folio
Manual feed slot Width: 76.2 to 216 mm (3.0 to 8.5 inch)
Length: 116 to 406.4 mm (4.6 to 16 inch)
Duplex
(Only for duplex
printing models)
For U.S.A.: Letter, Legal, Folio
Except for U.S.A.: A4
ADF (Only for
ADF models)
Width: 147.3 to 215.9 mm (5.8 to 8.5 inch)
Length: 147.3 to 355.6 mm (5.8 to 14 inch)
*1 Legal size paper and Folio size paper are not available in some regions outside the U.S.A.
and Canada.

Brother DCP-7060D Specifications

General

Dimensions (WxDxH)	405 x 399 x 268 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Digital sender	No
Maximum duty cycle	- pages per month
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, Image, OCR
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	2.63 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Processor family	ARM
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
AC input frequency	50 - 60 Hz
Power consumption (standby)	55 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	445 W
Sustainability certificates	ENERGY STAR
Package weight	13.200 g
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
