Brother DCP-7060D Service Manual

5-40
Confidential
2.2 Parts Life Reset Function
This function is used to reset the relevant part counter when the user replaced a periodical
replacement part with the correct procedure, and also used to forcibly reset the relevant part
counter when an error cannot be resolved because the user did not replace a consumable
part with the correct procedure.
(1) Press the 3 and 9 buttons at the same time in the ready state.
(2) The “Reset Menu” will appear on the LCD. Select the applicable periodical replacement
part or consumable part by pressing the or button and press the OK button.
<Periodical replacement parts or consumable part are indicated on the LCD>
•Drum
(3) Once “1.Reset 2.Exit” appears on the LCD; press the 1 or 2 button.
(4) The machine implements clearing the counter.
2.3 Deletion of User Setting Information, etc.
In this machine, the user setting information is stored in the EEPROM and flash memory of
the main PCB ASSY. You can delete all the data listed below at a time with the procedure
given below.
• Information related to Net
• User setting information
<Operating Procedure>
(1) Press the Menu button while the machine is in the ready state.
(2) Press the or button, then the “Initial Setup” or “General Setup” will appears on the
LCD and press the OK button.
(Which will appear, “Initial Setup” or “General Setup”, depends on the model.)
(3) Press the or button, then the “Reset Menu” will appear on the LCD and press the
OK button.
(4) Press the or button, then the “All Settings” will appear on the LCD and press the
OK button.
(5) The “1.Reset 2.Exit” appear on the LCD.
(6) Press the 1 button, and the user setting information is deleted, and the machine goes
back to the ready state.
Note:
• This function is not available on models without the numeric keys.
• All replacement parts are always indicated on the LCD even though their lives do not
reach the end of life.
• The machine returns to the ready state automatically if no panel operation is
implemented for 30 seconds.
Note:
• The machine returns to the ready state automatically if no panel operation is
implemented for 30 seconds.

Brother DCP-7060D Specifications

General

Dimensions (WxDxH)	405 x 399 x 268 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Digital sender	No
Maximum duty cycle	- pages per month
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, Image, OCR
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	2.63 ppm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Processor family	ARM
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
AC input frequency	50 - 60 Hz
Power consumption (standby)	55 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	445 W
Sustainability certificates	ENERGY STAR
Package weight	13.200 g
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
