Brother DCP-7060D Service Manual

2-31
Confidential
Error code 35
Error, which cannot be specified, occurs.
■ Error code 36
Error in the high voltage power supply PCB while the machine is in the ready state.
■ Error code 37
These errors do not usually occur in the normal use. The conceivable causes are noise around
the installation site, fluctuation of the power supply voltage, and failures in the software.
Error, which cannot be specified, occurs.
Error code 38
Error, which cannot be specified, occurs.
Error code 39
Error, which cannot be specified, occurs.
Print Unable 35
Turn the power off and then back on again.
<User Check>
• Turn OFF the power switch, and turn it ON again after a while.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Print Unable 36
Turn the power off and then back on again.
Step Cause Remedy
1
Harness connection failure of high
voltage power supply PCB
Check the harness connection of the high
voltage power supply PCB and reconnect
it.
2
High voltage power supply PCB
failure
Replace the high voltage power supply
PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
Print Unable 37
Turn the power off and then back on again.
Print Unable 38
Turn the power off and then back on again.
Print Unable 39
Turn the power off and then back on again.
