4-8 Confidential
Error Code
(Hex)
Symptom Probable Cause Solution
Foreign materials in the
machine
Remove foreign materials.
Clutch gear broken Replace the clutch gear.
PF encoder disk being in
contact with the upper
cover and deformed
Replace the PF encoder
disk.
PF encoder PCB
defective
Replace the PF encoder
PCB.
Main drain tube bent
Replace the main drain
tube.
Purge cam gear broken
Abnormal load applied
to the purge cam
Replace the maintenance
unit.
Planetary arm assembly
broken
Replace the maintenance
unit.
Main PCB defective Replace the main PCB.
Power supply PCB
defective
Replace the power supply
PCB.
Paper feed motor
defective
Replace the paper feed
motor.
54
55
The tube pump rotates
abnormally.
PF roller gear L broken Replace the engine unit.
56 Not used.
Head cap unit, head
wiper or other parts on
the maintenance unit
interfering with the
head/carriage unit
Set these parts back into
place.
If any part on the
maintenance unit does not
operate smoothly, replace
the unit.
CR encoder strip stained Clean the CR encoder
strip.
Any obstacles on the
travel path of the
head/carriage unit
Clean the CR guide rail
and CR support chassis.
Carriage motor defective Replace the carriage
motor.
Head/carriage unit
defective
Replace the head/carriage
unit.
Main PCB defective Replace the main PCB.
57 After a purging operation,
the head/carriage unit will
not return to the home
position (capping
position).
Power supply PCB
defective
Replace the power supply
PCB.
