Brother DCP130C - Page 99

4-9 Confidential
Error Code
(Hex)
Symptom Probable Cause Solution
58, 59 Not used.
Foreign materials in the
machine
Remove foreign materials.
Clutch gear broken Replace the clutch gear.
5A The purge cam stops
abnormally when it is in
operation.
PF encoder disk being in
contact with the upper
cover and deformed
Replace the PF encoder
disk.
PF encoder PCB
defective
Replace the PF encoder
PCB.
Main drain tube bent Replace the main drain
tube.
5B The tube pump stops
abnormally during air
venting.
Purge cam gear broken
Abnormal load applied
to the purge cam
Replace the maintenance
unit.
Planetary arm assembly
broken
Replace the maintenance
unit.
Main PCB defective Replace the main PCB.
Power supply PCB
defective
Replace the power supply
PCB.
Paper feed motor
defective
Replace the paper feed
motor.
5C The tube pump stops
abnormally during purging
operation.
PF roller gear L broken Replace the engine unit.
Remove foreign materials.
Replace the clutch gear.
Replace the PF encoder
disk.
Replace the PF encoder
PCB.
5D Current protection for the
driver IC activated when
the purge cam was being
driven.
Replace the main drain
tube.
Replace the maintenance
unit.
Replace the main PCB.
Replace the power supply
PCB.
Replace the paper feed
motor.
5E Current protection for the
driver IC activated when
the pump was in operation.
The driving current has
exceeded the limit due to
an abnormal load applied
to the maintenance unit.
Replace the engine unit.
