Brother HL-5450DN Technical Reference Guide

CHAPTER 3 PCL5C - 16
6. HP-GL/2
A few HP-GL/2 commands are added for the HL-2400C/Ce, HL-3400CN, HL-2600CN, HL-3450CN, HL-
2700CN, HL-
4040CN/4050CDN/4070CDW/3070CW/3075CW/4140CN/4150CDN/4570CDW/3170CDW/L8250CDN/L835
0CDW/L9200CDW/L9300CDW color laser printer, and the features of some existing commands are also
expanded.
The new or revised HP-GL/2 commands as follows are described in this chapter;
 Initialize Set Instruction (IN) - resets all programmable functions to their default settings
 Pen Color (PC) - changes the palette colors
 Number of Pens (NP) - changes the palette size
 Color Range (CR) - sets the range for specifying relative color data
For the basic commands of HP-GL/2, refer to 'Chapter 8 HP-GL/2 Graphics Language'.
6.1. IN (Initialize Set Instruction) Command
Command
IN [;]
This command returns the graphics mode to initial conditions. It initializes the parameters listed on Page.9 of
'Chapter 8 HP-GL/2' and also those shown below.
Function Equivalent
Instruction
Condition
Number of Pens NP 8
Color Range CR Black reference (red, green, blue) ----> 0
White reference (red, green, blue) ----> 255
This command also initializes the parameters of the palette as follows;
Palette No.(Pen No.) Color
0 White
1 Black
2 Red
3 Green
4 Yellow
5 Blue
6 Magenta
7 Cyan
6.2. PC (Pen Color) Command
Command
PC [pen, red, green, blue]
PC [pen;]
PC [;]
This command changes the pen colors in the palette and sets the colors of all pens to their default settings.
 pen: represents the palette number specified by this command. It ignores the command if it is out of
the range of the specified parameter.
 red, green, blue: specifies the color. The range of the specified value is determined by the CR command.
Default range is 0 ~ 255.
 PC [;]: initializes all palettes.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
