Brother HL-5450DN Technical Reference Guide

CHAPTER 2 PCL - 54
Symbol map (Array of UI )
The symbol map, which has a list of symbol index numbers, is used to define the symbols for the symbol set.
This map defines the combinations of symbol index numbers and character codes.
5.2.4. Symbol set control command
Esc*c#S (27)(42)(99)#(83) <1Bh><2Ah><63h>#<53h>
 Values for # can be 0, 1, 2, 4, or 5.
 0 specifies to delete all temporary and permanent user-defined symbol sets.
 1 specifies to delete all temporary user-defined symbol sets.
 2 specifies to delete current user-defined symbol set.
 4 specifies to make current user-defined symbol set temporary.
 5 specifies to make current user-defined symbol set permanent.
5.2.5. Selecting the symbol set
Esc(symbol set ID (27)(40) <1Bh><28h>
 This command selects the symbol set (character set) for the primary font.
 Symbol set IDs consist of a number followed by a letter.
 Default symbol set ID is Roman-8. If an invalid default symbol set ID is selected, the symbol set becomes
Roman-8.
 The selectable symbol set varies depending on the printer model.
Symbol set Set primary font Symbol set Set primary font
ISO 60 : Norwegian 1 Esc(0D ISO 57 : Chinese Esc(2K
ISO 61 : Norwegian 2 Esc(1D ISO8859-1 (ECMA-94) Latin
1
Esc(0N
ISO 4 : United Kingdom Esc(1E Wingdings Esc(579L
Windows 3.1 Latin 2 Esc(9E PS Math Esc(5M
ISO 25 : French Esc(0F Ventura Math Esc(6M
ISO 69 : French Esc(1F Math-8 Esc(8M
HP German Esc(0G Symbol Esc(19M
ISO 21 : German Esc(1G ISO 8859-2 Latin 2 Esc(2N
ISO 15 : Italian Esc(0I ISO 8859-9 Latin 5 Esc(5N
Microsoft Publishing Esc(6J ISO 11: Swedish; names Esc(0S
Desk Top Esc(7J PS Text Esc(10J
HP Spanish Esc(1S Ventura International Esc(13J
ISO 17 : Spanish Esc(2S Ventura US Esc(14J
ISO 10 : Swedish Esc(3S ISO 16 : Portuguese Esc(4S
ISO 14 : JIS ASCII Esc(0K ISO 84 : Portuguese Esc(5S
ISO 85 : Spanish Esc(6S Windows 3.1 Latin 5 Esc(5T
PC Turkish Esc(9T ISO 6 : ASCII Esc(0U
Legal Esc(1U ISO 2 : IRV Esc(2U
Roman 8 Esc(8U Windows 3.0 Latin 1 Esc(9U
PC-8 Esc(10U PC-8 D/N Esc(11U
PC-850 Esc(12U Pi Font Esc(15U
PC-852 Esc(17U Windows 3.1 Latin 1 Esc (19U
MC Text Esc(12J ISO 8859-10 Latin 6 Esc (6N
OCR-A Esc(0O OCR-B Esc(1O

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
