Brother HL-5450DN Technical Reference Guide

CHAPTER 2 PCL - 46
5. USING FONTS
5.1. Introduction
A font is a collection of characters that have common characteristics, such as size, style and typeface, and which
ranges over a given set of symbols. For example, 12 point Tennessee Bold in the Roman-8 symbol set is a
typical HL Series font. Different sorts of fonts are used to create various typographic effects. Traditionally, large
point size sans serif typeface fonts, like Helsinki and Utah are used for document headlines while smaller fonts
with serif typefaces, like Tennessee and Portugal are used for body text. In LaserJet mode you can have access
to a large range of fonts that are already built in to the printer's ROM, plus the facility for downloading more
fonts from a personal computer or plugging in font cards/cartridges or the storage device. When you select a
font for printing you will specify a number of characteristics which identify the font you require. The laser / ink
printer does its best to print using the font you specified, but if amongst all its available fonts it does not have
the exact one that you specified, it will compromise and give you what it regards as the closest available font.
Sometimes the results will not be what you expected and you should exercise care in selecting fonts for printing.
In most instances the selection of a font will be handled automatically from your word processing software or
other applications package. In these cases you need only ensure that the correct font is available (that is, as a
standard font in the ROM, on cartridge/card or downloaded) and the application will do the rest. You do not
need to concern yourself with sending any escape sequences.
As well as using software commands you can also select fonts using the printer's control panel. Consult the
printer User Guide for details.
5.1.1. Font types
There are two types of fonts supported by the HL Series printers in LaserJet mode - bitmap fonts and scalable
fonts.
5.1.2. Bitmap fonts
The characters which make up a bitmap font are raster bit images of the relevant symbols. When text is printed
using the font it is nearly always monospaced and when you select the font you specify it by its typeface, pitch
(the number of characters printed per inch), height (point size) and symbol set.
5.1.3. Scalable fonts
The printer has many scalable fonts available as standard. The following table shows scalable fonts available
for models HL-1050/1070/1250/1270N/1450/1470N/P2500/1660e/2060/2400C/2400Ce/
3400CN/1650/1670N/2460/7050/1850/1870N/5040/5050/5070N/5140/5150D/5170DN/2600CN/3450CN/6050/
6050D/6050DN/8050N/2700CN/2070N/4040CN/4050CDN/4070CDW/2150N/2170W/5240/5250DN/5270DN/
5280DW/5340D/5350DN/5370DW/5380DN/3070CW/3075CW/2250DN/2270DW/4140CN/4150CDN/4570C
DW/L2360DN/L2360DW/L2365DW/2560DN/2569DW/S7000DN. (For the other models' resident fonts,
please see the printer User's Guide.)
Intellifont Compatible Fonts:
HL-1050/1070/1250/1270N/1450/1470N/P2500/1660e/
2060/2400C/2400Ce/3400CN/1650/1670N/3260N/
2460/7050/1850/1870N/5040/5050/5070N/5140/
5150D/5170DN/2600CN/3450CN/6050/6050D/
6050DN/8050N/2700CN/2070N/5240/5250DN/5270
DN/5280DW/4040CN/4050CDN/4070CDW/2150N/2
170W/5340D/5350DN/5370DW/5380DN/3070CW/3
075CW/2250DN/2270DW/4140CN/4150CDN/4570C
DW/5440D/5450DN/5470DW/6180DW/S7000DN/31
70CDW/L8250CDN/L8350CDW/L9200CDW/
L9300CDW/L2360DN/L2360DW/L2365DW/25
60DN/2569DW
Alaska Medium, Extra Bold

Antique Oakland Medium, Oblique, Bold

PcBrussels Light, Light italic, Demi, Demi italic

Oklahoma Medium, Oblique, Bold, BoldOblique

Cleveland Condensed

Connecticut

Brougham Medium, Oblique, Bold, Bold oblique

Guatemala Antique, Italic, Bold, Bold italic

LetterGothic Medium, Oblique, Bold


Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
