APPENDIX D REFERENCE LIST OF MX-2000/4000/5000/7000 SERIES UNIQUE COMMANDS - 5
3. COMMAND REFERENCE LIST
This section describes the specific commands as listed below used to support the functions of the Mailbox unit.
1) PJL output tray & mode setting
2) PJL mailbox protection & bin number setting
3) PJL avoidance of output bin full
4) PCL output tray setting
5) PS output tray & mode setting
6) PS mailbox protection & bin number setting
For the details on each command, refer to the following sections.
3.1. Commands Descriptions
3.1.1. PJL output tray & mode setting
Format
@PJL SET/DEFAULT OUTBIN=TrayName
Parameter
TrayName*
 UPPER:
Select the printer face-down output tray.
 OPTIONALOUTPUTBIN1:
Select the #1 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN2:
Select the #2 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN3:
Select the #3 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN4:
Select the #4 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN5:
Select the #5 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN6:
Select the #6 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN7:
Select the #7 bin of the Mailbox unit.)
 OPTIONALOUTPUTBIN8:
Select the #8 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN9:
Select the #9 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN10:
Select the #10 bin of the Mailbox unit.
 ALLSTACKER:
Select the stacker function. **
 ALLSORTER:
Select the sorter function. **
* = The tray names are compatible with the HP tray naming.
** = These are unique tray names (parameters).
Default = ALLSTACKER
Explanation
 This command selects the specified output tray and output mode, trays defined as Mailboxes are numbered
from the bottom of the unit upwards
 This command is ignored when there is no specified tray.
 The ALLSTACKER and ALLSORTER parameters are executed for all output trays other than the ones which
are defined and protected as mailboxes. (Refer to Section 3.1.2 'PJL mailbox protection & tray number
setting'.)
 The difference between the SET and DEFAULT selection and the effective period of this setting follow the
PJL specifications.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
