Brother HL-5450DN Technical Reference Guide

CHAPTER 3 PCL5C - 5
2.2. Using PCL Color Mode - Set PCL Color Setting
Command
ESC*v#W (27)(42)(118)#(87) <1Bh><2Ah><76h>#<57h>
# = 6, 18
# stands for the number of bytes of data that follow this command.
This command sets the palette size and transformation between the entered value and device-specific value.
This command has two types of format, short format and long format. Here are the formats for the PCL
color setting.
1) Short Format
MSB LSB
0 - 1 Format (0) Encoding mode
2 - 3 Bits / index Bits / value #1
4 - 5 Bits / value #2 Bits / value #3
♣ Format
This value must be 0.
♣ Encoding mode
 This value defines how to send the raster image data.
 The value can be from 0 to 3 only, other values are ignored.
Encoding Mode
0 Send Index No by Plane *
1 Send Index No by Pixel
2 Send Direct Value by Plane
3 Send Direct Value by Pixel
* = default
Send Index No by Plane (= 0 default)
 This mode assigns the Index No. to the Plane, then sends it.
 The necessary number for the Plane is determined depending on the number of bits/index. 1 (one) plane
should be needed per 1 (one) bit/index. For instance, 4 planes are needed for 4 bits/index.
 Bits/index must be 1, 2, 4, 5, 6, 7, 8.
 This mode sends the plane data except the last one using the Send Raster Data by Plane command
(ESC*b#V).
 This mode also sends the last plane data using the Send Raster Data command (ESC*b#W).
(i.e. 4 bits/index)
ESC*b#V d1, d1, d1, d1, d1 ... Plane 1 1st raster
ESC*b#V d2, d2, d2, d2, d2 ... Plane 2
ESC*b#V d3, d3, d3, d3, d3 ... Plane 3
ESC*b#W d4, d4, d4, d4, d4 ... Plane 4
ESC*b#V d1, d1, d1, d1, d1 ... Plane 1 2nd raster
ESC*b#V d2, d2, d2, d2, d2 ... Plane 2
MSB LSB
Index No.
d4 d3 d2 d1
** The Italic characters shown above are the index No. at the 4th pixel in the 1st raster.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
