CHAPTER 4 HP-GL/2 - 13
IN - Initialize set instruction
IN[;]
Returns the graphics mode to initial conditions;
Function Equivalent
Instruction
Condition
Plot mode PA; Absolute plotting
Relative character direction DR 1,0; Horizontal
Line type LT; Solid line
Line pattern length LT; 4% of distance from P1 to P2
Window IW; Set at limits of printable area according to
paper size
Symbol mode SM; Off
Anchor corner AC; Lower left corner of picture frame
Line attributes LA; Butt caps, mitered joins, miter limit = 5
User-defined line type UL; All line types set to default
Pen SP; Select white pen
Pen position PA0,0; HP-GL/2 origin
Character set SS; Standard character set selected
Character size transformation SI; Off
Scalable or bitmap fonts SB0; Scalable only
Character slant SL 0; 0 degrees
Character fill CF; Solid fill
Scaling SC ; Off
Label terminator DT chr$(3) chr$(3)
Raster fill RF; Solid black
Fill type FT; Bi-directional fill, type 1
Transparency mode TR1; Transparency mode on
Screened vectors SV; No screening
Polygon mode PM0PM2; Polygon buffer empty
Standard font SD; Stick font
Alternate font AD; Stick font
Pen condition PU; Pen up
Pen width type WU; Metric
Pen width PW; Set at 0.35 mm
Label origin LO1; Current pen location
Text path DV; Left to right with normal line feed
Rotation RO; Set at 0 degrees
Extra space ES; No extra space
Transparent data TD; Normal printing mode
Scaling points IP; Initialized according to paper size
