Brother HL-5450DN Technical Reference Guide

CHAPTER 2 PCL - 68
Symbol set name Symbol set ID Symbol set name Symbol set ID
Default Se
t
0
@
Math-7 0A
Line Draw-7 0B HP Lar
g
e Characters
(
264x Terminals
)
0C
ISO 60: Danish/Norwe
g
ian 0D ISO 61: Norwe
g
ian version 2 1D
Roman Extensions 0E ISO 4: United Kin
g
do
m
1E
ISO 25: French 0F ISO 69: French 1F
HP German 0G ISO 21: German 1G
Gree
k
-8 8G Hebrew-7 0H
Hebrew-8 8H ISO 15: Italian 0I
Microsoft Publishin
g
6J DeskTo
p
7J
Documen
t
8J PS Tex
t
10J
Ventura International 13J Ventura US 14J
ISO 14: JIS ASCII 0K ISO 13: Katakana 1K
ISO 57: Chinese 2K Kana-8 8K
Korean-8 9K Line Draw-7
(
Same as 0B
)
0L
HP Block Characters 1L Tax Line Draw 2L
Line Draw-8 8L Math-7
(
Same as 0A
)
0M
Tech-7 1M PS Math 5M
Ventura Math 6M Math-8 8M
ECMA-94 Latin 1
(
ISO 8859/1
)
0N ECMA-94 Latin 2
(
ISO 8859/2
)
2N
ECMA-128 Latin 5
(
ISO 8859/9
)
5N ECMA-113/88 Latin/C
y
rillic 10N
OCR A 0O OCR B 1O
OCR M 2O APL
(
T
yp
ewriter Paired
)
0P
APL
(
Bit Paired
)
1P S
p
ecials x
Q
C
y
rillic ASCII
(
ECMA-113/86
,
0R C
y
rillic 1R
PC C
y
rillic 3R ISO 11: Swedish for Names 0S
HP S
p
anish 1S ISO 17: S
p
anish 2S
ISO 10: Swedish 3S ISO 16: Portu
g
uese 4S
ISO 84: Portu
g
uese 5S ISO 85: S
p
anish 6S
HP Euro
p
ean S
p
anish 7S HP Latin S
p
anish 8S
HP-GL Download 16S HP-GL Draftin
g
17S
HP-GL S
p
ecial S
y
mbols 18S Turkish-8 8T
Thai-8 0T ISO 6: ASCII 0U
Le
g
al 1U ISO 2: International Reference Version 2U
HP-GL Lan
g
ua
g
e Se
t
5U OEM-1 7U
Roman-8 8U Windows 9U
PC-8 10U PC-8 D/N
(
Danish/Norwe
g
ian
)
11U
PC-850 12U PC-852 17U
Pi Fon
t
15U
Arabic (McKay
'
s version)
0V
Arabic-8 8V 3 of 9 Barcode 0Y
Industrial 2 of 5 Barcode 1Y Matrix 2 of 5 Barcode 2Y
Interleaved 2 of 5 Barcode 4Y CODABAR Barcode 5Y
MSI/Plesse
y
Barcode 6Y Code 11 Barcode 7Y
UPC/EAN Barcode 8Y USPS Zi
p
15Y
 Pitch (UI) - This value defines the default spacing for each point size in 1/4 dots. Combined with Pitch
Extended to specify the pitch of the font in 1/1024 dots. This is available for fixed pitch font characters
including the space character, and the space character of proportional spacing fonts.
For example, in case of a 17 cpi font (at 600 dpi),
= 141.17646
1 inch 600 dpi
4
17 chara.
1 inch 1
the value of Pitch (UI) should be 141.
The remainder of 0.17646 is calculated as pitch extended:
0.17646 256
4 1
= 45.17376
the value for pitch extended is 45.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
