4.10 Troubleshooting for PCB Problems
4.10.1 Main PCB failure
< User Check >
- Turn the power OFF/ON.
- Install the latest firmware.
- Check if PC-print is not prohibited.
- Check the print restricted ID.
- Replace the damaged DIMM.
- Check if print data is not damaged.
4.10.2 Full memory
< User Check >
- Print the stored data.
- Reduce the amount of data or lower the resolution.
4.10.3 Problem of print restriction/ID authentication
< User Check >
- Check if PC-print is not prohibited.
- Check the print restricted ID.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 ID is forgotten Execute Function code 01 to initialize the ID.
2 Main PCB failure Replace the main PCB ASSY.
