66
A
Replacing the consumable items A
The following messages appear on the LCD in the Ready mode. These messages provide
advanced warnings to replace the consumable items before they reach the end of their life. To
avoid any inconvenience, you may want to buy spare consumable items before the machine stops
printing.
The drum unit and toner cartridge are two separate consumables. Make sure both are installed
as an assembly. If the toner cartridge is placed in the machine without the drum unit, the
messages Drum Error or Jam Inside may be displayed.
Routine maintenance A
Toner cartridge Drum unit
See Replacing the toner cartridge uu page 69.
(For Oceania)
Model Name: TN-3310, TN-3340
(For Asia)
Model Name: TN-3320, TN-3350, TN-3370
See Replacing the drum unit uu page 75.
(For Oceania)
Model Name: DR-3325
(For Asia)
Model Name: DR-3355
TN-3310, TN-3340 / TN-3320, TN-3350
TN-3370
To Next Page
