3-19

Confidential

9

Speaker unit, Modem (LVPS side)

Harness colors are subject to change for some reason.

Modem FG harness R (GR)

Stack sensor harness

(RD, BK, WH)

Speaker harness

(RD, BK)

Modem flat cable

Modem FG harness L

(BK)

Flat core

Core
