3-57

Confidential

Fig. 3-51

Assembling Note:

• Fold the panel flat cable at the positions shown in the figure below.

Mountain fold

Valley fold

12±1

85±1

309±1

311±1

11±1

36±1

60±1

71±1

95±1

136±1

Panel PCB side

Main PCB side

45° 45° 45° 45°45°

Reinforcing plate Reinforcing plate
