1-6
Confidential
Model
MFC-L5800DW
MFC-L5802DW
MFC-L5850DW
MFC-L5900DW
MFC-L5902DW MFC-L6700DW MFC-L6702DW
Warm-up
time
From Sleep
mode
Less than 5.8 sec. at 73.4F / 50%RH
(23°C / 50%RH) for the U.S.A./Brazil
Less than 4.8 sec. at 73.4F / 50%RH
(23°C / 50%RH) except for the U.S.A./Brazil
Less than 5.7 sec. at 73.4F /
50%RH (23°C / 50%RH) for
the U.S.A./Brazil
Less than 4.7 sec. at 73.4F /
50%RH (23°C / 50%RH)
except for the U.S.A./Brazil
From Power
OFF
 ON
Less than 27 sec. at 73.4F / 50%RH (23°C / 50%RH)
First print
time
From Ready
mode
Less than 7.2 secs at 73.4F (23°C) Less than 7.5 secs at 73.4F
(23°C)
From Sleep
mode
Less than 13.0 secs at 73.4F (23°C) for the
U.S.A./Brazil
Less than 12.0 secs at 73.4F (23°C)
except for the U.S.A./Brazil
Less than 13.2 secs at
73.4F (23°C) for the U.S.A./
Brazil
Less than 12.2 secs at
73.4F (23°C) except for the
U.S.A./Brazil
Printing speed
(A4/Letter)
Up to 40/42 ppm
(Quiet Mode: Up to 25/26 ppm)
Up to 46/48 ppm
(Quiet Mode: Up
to 25/26 ppm)
except for Asia
Up to 50/52 ppm
(Quiet Mode: Up
to 25/26 ppm) for
Asia
Up to 46/48 ppm
(Quiet Mode: Up
to 25/26 ppm)
CPU Cortex-A9
800 MHz
Backup clock Up to 60 hours
Dimensions
(W x D x H)
Carton size 599 x 526 x 629 mm
(23.6 x 20.7 x 24.8 inch)
599 x 526 x 659 mm
(23.6 x 20.7 x 25.9 inch)
Machine
size
495 x 427 x 486 mm
(19.5 x 16.8 x 19.1 inch)
495 x 427 x 518 mm
(19.5 x 16.8 x 20.4 inch)
Weights
with carton 20.8 kg / 45.9 lb
(for the U.S.A.)
20.7 kg / 45.7 lb
(except for the
U.S.A.)
20.9 kg / 46.0 lb 20.8 kg / 45.8 lb 22.1 kg / 48.7 lb
(for the U.S.A.)
22.0 kg / 48.6 lb
(for Latin
America)
22.1 kg / 48.6 lb
(for Oceania)
22.6 kg / 49.8 lb
(for Asia)
22.0 kg / 48.6 lb
without
carton,
with toner/
drum
17.2 kg / 37.9 lb
(for the U.S.A.)
17.2 kg / 38.0 lb
(except for the
U.S.A.)
17.3 kg / 38.0 lb 17.3 kg / 38.1 lb 18.4 kg / 40.5 lb (except for Asia)
18.8 kg / 41.4 lb (for Asia)
without
carton and
toner/drum
15.9 kg / 34.9 lb
15.9 kg / 35.1 lb 17.0 kg / 37.5 lb
Specifications are subject to change without notice.
