Brother MFC-8540DN Service Manual

2-23
Confidential
Jam Rear Open the Back Cover
and remove the
jammed paper.
The eject sensor remains ON
(paper pass detected) even after
the registration rear sensor
detected the end of paper pass.
7100 2-51
Jam Tray1 Remove the jammed
paper from Tray 1.
When printing from the paper tray 1,
the registration front sensor does
not detect paper pass within the
specified time after the paper feed
sensor detected paper pass.
7302 2-53
Jam Tray2 Remove the jammed
paper from Tray 2.
When printing from the paper tray 2,
the registration front sensor or the
T2TT jam sensor does not detect
paper pass within the specified time
after the T2(LT or TT) paper feed
sensor detected paper pass.
7402 2-55
Jam Tray3 Remove the jammed
paper from Tray 3.
When printing from the paper tray 3,
the registration front sensor or the
T2/T3TT jam sensor does not detect
paper pass within the specified time
after the T3(LT or TT) paper feed
sensor detected paper pass.
7502 2-57
Jam Tray4 Remove the jammed
paper from Tray 4.
When printing from the paper tray 4,
the registration front sensor or the
T2/T3/T4TT jam sensor does not
detect paper pass within the
specified time after the T4(LT or TT)
paper feed sensor detected paper
pass.
7602 2-59
Jam Tray5 Remove the jammed
paper from Tray 5.
When printing from the paper tray 5,
the registration front sensor or the
T2/T3/T4/T5TT jam sensor does not
detect paper pass within the
specified time after the T5TT paper
feed sensor detected paper pass.
7702 2-61
Error message
Description
Error
codes
Refer
to:
First line Second line
