Brother MFC-8890DW Service Manual

3-32
Confidential
■ Error code AF
CCD model
CIS model
Document Scanner home position sensor is not turned off.
■ Error code B0
FFC for scanner module is not connected correctly or failure of the document scanner unit.
* This error is indicated on the LCD in the maintenance mode.
Scanner Locked
Open the Document Cover and release Scanner lock lever. Press Stop
key.
Scan Unable
See Troubleshooting and routine maintenance chapter in User's
Guide.
<User Check>
• Check that the scanner lock lever is unlocked.
- CCD model
Step Cause Remedy
1
Home position sensor harness not
connected correctly
Reconnect the home position sensor
harness.
2 Drive PCB failure Replace the drive PCB.
3 Belt broken Replace the belt.
4 Home position sensor failure Replace the home position sensor.
5 Scanner motor failure Replace the scanner motor.
6 Main PCB failure Replace the main PCB ASSY.
- CIS model
Step Cause Remedy
1 FFC cable not connected correctly Reconnect the FFC cable.
2 Drive PCB failure Replace the drive PCB.
3 Document scanner unit failure Replace the document scanner unit.
4 Main PCB failure Replace the main PCB ASSY.
Scanner Error
Step Cause Remedy
1
Harness for scanner module not
connected correctly.
Reconnect the harness for the CCD unit
correctly. (CCD model)
Reconnect the harness for the document
scanner unit correctly. (CIS model)
2 Scanner harness broken Replace the FFC cable ASSY.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-8890DW Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, e-Mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Output color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Custom media width	69.8 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Wi-Fi standards	802.11b, 802.11g
Security algorithms	LEAP
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	22100 g
Maximum duty cycle	30000 pages per month
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
