5-131
Confidential
■ CIS model
9.9.2
Panel Cover ASSY
(1) Remove the Panel cover ASSY.
Fig. 5-147
Note:
• In the case of the CCD model, refer to "9.9.1 Panel Cover ASSY".
Hooks
Hooks
Hooks
Panel cover ASSY
