Brother MFC-8890DW Service Manual

7-30
Confidential
4.14 Received Data Transfer Function
(Function code 53) (only model with FAX)
<Function>
This function transfers received FAX data to another machine. It is useful when the machine
cannot print received data due to the printing mechanism being defective. And this function
faxes the maintenance information of the machine.
<Operating Procedure>
(1) Press the [5] and [3] keys in this order in the initial stage of the maintenance mode.
The “FAX TRANSFER” appears on the LCD.
(2) To check the number of received files
, press the [1] key.
The “1.NO. OF JOBS” appears on the LCD.
Press the [OK] button, and the number of received files appears, just as “NO. OF. JOBS:
10.”
(3) To transfer the activity report only
, press the [2] key.
The “2.ACTIVITY” appears.
To transfer received files (together with the activity report)
, press the [3] key.
The “3.DOCUMENTS” appears. Note that if there is no received file, the “NO
DOCUMENTS” appears.
(4) To transfer the communication list for the latest communication
, press the [4] key.
The “4.COM.LIST (NEW)” appears.
To transfer the communication list for last three errors
, press the [5] key.
The “5.COM.LIST (ERR3)” appears.
(5) Press [6] key to transfer the maintenance information (list of function code 77).
The “6.MNT77 LIST” appears on the LCD.
(6) With the “2.ACTIVITY,” “3.DOCUMENTS,” “4.COM.LIST (NEW),” “5.COM.LIST (ERR3),”
or “6.MNT77 LIST” being displayed, press the [OK] button.
The “ENTER NO. & SET” appears.
(7) Enter the telephone number of the receiver machine and press the [OK] button again.
Note:
• The number of files that can be transferred at a time
is 99. To transfer 100 files or
more, carry out the following procedure more than one time.
TIP:
• If there are both color and monochrome data in a file to be transferred, the
monochrome data will be transferred first. If the receiver machine does not support
the color function, the sender machine cannot transfer color data, resulting in an
error.
Note:
• Be sure to type the telephone number with the numerical buttons. No one-touch
dialing is allowed in this procedure.
The machine displays the “ACCEPTED” for approx. two seconds and starts
dialing to transfer data.
No station ID will be attached. A cover page and end page as shown on the
next page will be automatically attached, instead.

Brother MFC-8890DW Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, e-Mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Output color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Custom media width	69.8 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Wi-Fi standards	802.11b, 802.11g
Security algorithms	LEAP
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	22100 g
Maximum duty cycle	30000 pages per month
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
