4.11 PC Print Function (Function code 43)
<Function>
This function allows the machine change that the setting of each PC printing function
indicated to the following function settings.
<Operating Procedure>
(1) Press the [4] and [3] keys in this order in the initial stage of the maintenance mode.
The “Manual Feed” will appear on the LCD.
(2) Press the [ ] or [ ] buttons to select the function you want to set and press the [OK]
button.
(3) When select the unchanging (On/Off) parameter, press the [ ] or [ ] button to change
the parameter, then press the [OK] button.
When select the parameter of the numeric input, enter the numeric value using the
numeric keys directly, then press the [OK] button.
(4) If press the [Stop/Exit] button, the machine will return to the initial stage of the
maintenance mode.
■ Function setting
LCD indication Description Set value
Initial
value
Manual Feed Switching of the Manual Feed On/Off Off
Resolution Resolution to print 300/600/1200dpi 600
Toner Save Switching of the Toner Save On/Off Off
Density Switching of the Density level -6 to 6 0
JB-Can Time Setting of the time until the host
time-out at the Job Cancel
2 to 225 (seconds)
4
Sleep Time Setting of the time until enter the
Sleep Mode
0 to 99 (minutes)
5
Page
Protection
Switching of the protection of the
page memory
Off/Letter/A4/Legal/Auto
Off
Emulation Switching of the emulation Auto/HP/PS Auto
Auto I/F Time Switching of the I/F open time 1 to 99 (seconds) 5
Media Type Switching of the recording paper
type
Thin/Plain/Thick/Thicker/
Trancparency/Recycled/
Bond/Envlopes/EnvThin/
EnvThick
Plain
or
Thin
Paper Size Switching of the area of develop the
Letter/Legal/A4/
Executive/B5/JISB5/A5/
B6/A6/Monarch/C5/
COM10/DL/DLL/
A4Long/PostCard/Folio
Letter
or
A4
Copies Switching of the print copies 1 to 99 (pages) 1
Orientation Switching of the print direction PortLait/Landscape Portlait
P-Pos X-Offset Switching of the offset print position
of the landscape orientation
-500 to 500 (1/300dpi)
0
P-Pos Y-Offset Switching of the offset print position
of the portrait orientation
-500 to 500 (1/300dpi)
0
