■ Detail description
AutoFF Switching of the auto form feed On/Off Off
AutoFF Time Switching of the time-out period of
the auto feed
1 to 99 (seconds)
5
FF Surpress Switching of the FF suppress On/Off Off
Auto LF Switching of the auto LF On/Off Off
Auto CR Switching of the auto CR On/Off Off
Auto WRAP Switching of the auto CRLF at the
print width
On/Off
Off
Auto SKIP Switching of the SKIP at the back-
end/tip of the recording paper
On/Off
On
Left Margin Switching of the margin at the left
end
0 to 145 (columus)
0
Right Margin Switching of the margin at the right
end
10 to 155 (columus)
80
Top Margin Switching of the margin at the upper
end
0 to 2.00 (inches)
0.5
Bottom Margin Switching of the margin at the
bottom end
0 to 2.00 (inches)
0.5
Lines Number of the text lines in the page 5 to 128 (lines) 60
Error Print Switching of the Error Print of the
Post Script
On/Off
On
LCD indication Detail description
Manual Feed Effective for the print from the PC, or for the print of the NetWorkConfig/
TestPrint/Fontlist/Configuration from the panel. When select the tray on
the PC, the setting becomes effective. And this setting is ignored.
Resolution Effective only for the print from the PC. When set the Resolution on the
PC, the setting becomes effective. And this setting is ignored.
Toner Save Effective for all print, and change the setting of the Function Menu.
However, as for the Copy, this setting becomes invalid. When set the
Toner Save or the PC, the setting becomes effective. And this setting is
ignored.
Density Effective for the print from the PC, or for the print of the NetWorkConfig/
TestPrint/FontList/Configuration from the panel. Link the setting of the
Toner Save. Judge the both setting, and decide the density. When set
the Density or the PC, the setting becomes effective. And this setting is
ignored.
JB-Can Time Configure the setting for until the host time-out at the Job Cancel.
The setting value is the second time scale.
Sleep Time Configure the setting for the time until shift to the Sleep Time. Change
the setting of the Function Menu.
Page
Protection
Configure the setting to protect the page memory, when recording in PC.
Set in the PCL-Core. There is not the influence of the memory
management problem of the MFC.
Emulation Configure the setting for the Emulation. Charge the setting of the
Function Menu. When the data include the ENTER LANGUAGE, the
setting becomes effective. And this setting is ignored.
LCD indication Description Set value
Initial
value

Brother MFC-8890DW Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, e-Mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Output color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Custom media width	69.8 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Wi-Fi standards	802.11b, 802.11g
Security algorithms	LEAP
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	19 W
Power consumption (average operating)	680 W
Package weight	22100 g
Maximum duty cycle	30000 pages per month
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
