Control panel setup
39
4
Ethernet (wired network only) 4
Ethernet link mode auto allows the print server to operate in 100BASE-TX full or half duplex or in 10BASE-T
full or half duplex mode by auto negotiation.
NOTE
If you set this value incorrectly, you may not be able to communicate with your print server.
Wired Status (For DCP-9020CDN, DCP-9020CDW, MFC-9140CDN,
MFC-9330CDW and MFC-9340CDW) 4
This field displays the current wired network status.
Setup Wizard (wireless network only) 4
The Setup Wizard guides you through the wireless network configuration. (For more information:
see Quick Setup Guide or Manual configuration from the control panel on page 19.)
WPS (Wi-Fi Protected Setup)/AOSS™ (wireless network only) 4
If your WLAN access point/router supports either WPS (PBC
1
) or AOSS™ (Automatic Wireless mode), you
can configure the machine easily. (For more information: see Quick Setup Guide or One push configuration
using WPS (Wi-Fi Protected Setup) or AOSS™ on page 27.)
1
Push Button Configuration
WPS (Wi-Fi Protected Setup) w/PIN Code (wireless network only) 4
If your WLAN access point/router supports WPS (PIN Method), you can configure the machine easily. (For
more information, see Configuration using the PIN Method of WPS (Wi-Fi Protected Setup) on page 29.)
WLAN Status (For DCP-9020CDW, MFC-9130CW, MFC-9330CDW and
MFC-9340CDW) 4
Status 4
This field displays the current wireless network status.
Signal 4
This field displays the current wireless network signal strength.
