Brother MFC-9460CDN Service Manual

2-105
Confidential
■ Paper fails to be supplied from the MP tray (Error code 27, etc)
- Check if the Tray Use setting is fixed to other tray.
- Check if the paper is loaded into the MP tray correctly.
- Check if the thickness of the paper is 60 to 163 g/m
2
.
Step Cause Remedy
1 Operation failure of the actuator
of the MP paper empty sensor
Uninstall and reinstall the actuator of the
MP paper empty sensor.
2 Harness connection failure of
PF drive motor
Check the harness connection of the
PF drive motor and reconnect it.
3 MP paper pick-up roller worn out Replace the MP paper feeding kit.
4 MP paper empty sensor failure Replace the MP paper empty/registration
front sensor PCB ASSY.
5 MP sector solenoid failure Replace the MP sector solenoid.
6PF drive motor failure Replace the PF plate ASSY.
7 Engine PCB failure Replace the engine PCB ASSY.
8 Main PCB failure Replace the main PCB ASSY.
