1.4.22 Frame pattern print (One-sided) (Function code 69)
<Function>
This function allows you to print one page of the frame pattern of the external circumference in
one-sided printing and check if there is any deviation or omission of print.
<Operating procedure>
(1) Load Letter-size paper on the paper tray.
(2) Press the 6 and 9 buttons in this order in the initial state of the maintenance mode.
"PRINTING" is displayed on the LCD, and one page of the frame pattern (refer to the
figure below) in one-sided printing. When print is completed, "WAKU SX" is displayed on
the LCD.
(3) Press the Stop/Exit button to return to the machine to the initial state of the maintenance
mode.
When an error message is displayed on the LCD, take the measures described in the
table below.
* # indicates the toner color (K, Y, M, or C) of which cartridge became empty.
Fig. 5-26
Note:
When printing fails, a relevant error is displayed on the LCD. Remove the cause of
error and press the Start/Black button, and the product automatically goes back to the
executable state, and "WAKU SX" is displayed on the LCD. Press the OK button, and
"PRINTING" is displayed on the LCD, and one page of the frame pattern is printed in
one-sided printing.
Error message Measure
TONER EMPTY # * Replace the empty toner cartridge and press the Start/Black
button to clear the error.
Cover is Open Close the front cover.
No Paper Replenish the letter-size paper in the tray and press the
Start/Black button to clear the error.
Jam Tray1 Remove the jammed paper, and press the Start/Black
button to clear the error.
Jam Rear
To Next Page
