Level 3 Level 4 Level 5 Descriptions
WLAN(Wi-Fi) TCP/IP BOOT Method
Select the Boot method that best suits your
needs.
IP Address
Enter the IP address.
Subnet Mask
Enter the Subnet mask.
Gateway
Enter the Gateway address.
Node Name
Enter the Node name.
WINS
Configuration
Select the WINS configuration mode.
WINS Server
Specify the IP address of the primary or
secondary WINS server.
DNS Server
Specify the IP address of the primary or
secondary DNS server.
APIPA
Set the machine to allocate the IP address
from the link-local address range
automatically.
IPv6
Turn the IPv6 protocol on or off.
WPS/Push Button
- Configure your wireless network settings
using the one-button push method.
WPS/PIN Code
- Configure your wireless network settings
using WPS with a PIN.
WLAN Status Status
View the current wireless network status.
Signal
View the current wireless network signal
strength.
SSID
View the current SSID.
Comm. Mode
View the current Communication mode.
MAC Address
- View the machine's MAC address.
WLAN Enable
- Turn the wireless network connection On or
Off.
Wi-Fi Direct Manual
- Configure your Wi-Fi Direct network settings
manually.
Group Owner
- Set your machine as the Group Owner.
Push Button
- Configure your Wi-Fi Direct network settings
using the one-button push method.
PIN Code
- Configure your Wi-Fi Direct network settings
using WPS with a PIN code.
Device
Information
Device Name
View your machine's device name.
SSID
View the Group Owner's SSID.
When the machine is not connected, the LCD
displays Not Connected.
IP Address
View your machine's current IP Address.
Status
Information
Status
View the current Wi-Fi Direct network status.
Signal
View the current Wi-Fi Direct network signal
strength.
When your machine acts as Group Owner, the
LCD always indicates a strong signal.
I/F Enable
- Turn the Wi-Fi Direct connection on or off.
Web Connect
Settings
Proxy Settings Proxy Connection
Change the Web connection settings.
Address
588
