Chapter 6
38
Multi-line connections (PBX) 6
We suggest you ask the company who
installed your PBX to connect your machine.
If you have a multi-line system, we suggest
you ask the installer to connect the unit to the
last line on the system. This prevents the
machine being activated each time the
system receives telephone calls. If all
incoming calls will be answered by a
switchboard operator, we recommend that
you set the Receive Mode to Manual.
We cannot guarantee that your machine will
operate correctly under all circumstances
when connected to a PBX. Any difficulties
with sending or receiving faxes should be
reported first to the company who handles
your PBX.
External and extension
telephones
6
Connecting an external
telephone 6
You can connect a separate telephone (2) to
your machine as shown in the diagram.
Before you connect the external telephone,
remove the protective cap (3) from the EXT.
jack.
Connect the telephone line cord to the jack
labeled EXT inside the machine.
Carefully guide the telephone line cord into
the cable channel and out the back of the
machine.
1 Extension telephone
2 External telephone
3 Protective Cap
