122
t Hold the handle of the toner cartridge
and slide the toner cartridge into the
drum unit, then gently pull it toward you
until you hear it click into place. Make
sure that you match the toner cartridge
colour to the same colour label on the
drum unit. Repeat this for all the toner
cartridges.
BK = Black, C = Cyan,
M = Magenta, Y= Yellow
u Make sure the blue lock lever (1) is in
the release position as shown in the
illustration.
v Gently slide the drum unit into the
machine until it stops at the blue lock
lever.
2
To Next Page
