100
Arranging Embroidery Designs (Layout & Editing)
E/V stitch
Select the E stitch or the V stitch.
E Stitch
1 Interval
Specify the distance
between strokes.
Narrow Wide
2 Stroke
width
Specify the stroke
height.
Short Long
3 Run
pitch
Specify the run pitch
(length of one stitch)
of the line.
Narrow Wide
Run time(s)
Specify the number of times the line
is sewn.
1 time 5 times
Stroke time(s)
Specify the number of times each
stroke is sewn.
1 time 3 times
Arrange
Specify the stroke direction (inside/
outside).
V Stitch
1 Interval
Specify the distance
between strokes.
Narrow Wide
2 Stroke
width
Specify the stroke
height.
Short Long
3 Run
pitch
Specify the run pitch
(length of one stitch)
of the line.
Narrow Wide
Run time(s)
Specify the number of times the
stitching is sewn.
With the V stitch, the line and the
strokes are sewn the same number
of times.
1 time 5 times
Arrange
Specify the stroke direction (inside/
outside).
1
2
3
12
3
