BSWA 308/309 BSWA Technology Co., Ltd
75
Instruction
Parameters
Explanation
CAF
Query parameter: ?
ASCII
C
A
F
?
Hex
43H
41H
46H
3FH
Byte
1
1
1
1
Return
Returns the most recent 4 group history of calibration.
Format “Year/Month/day, hour:minute:second, calibration factor, code”.
Code: M=By Measurement, F=By Calibration Factor.
Example: query the calibration history.
02 01 43 43 41 46 3F 03 38 0D 0A
Return: the data returned by this instruction use a slash “/” split date, use a colon “,” split time.
Calibration history is 2011/08/04, 17:03:28, +001.29, F, 2011/08/04, 17:03:02, +001.25, F,
2011/08/04, 17:02:20, +000.71, F, 2011/08/04, 17:02:00, +001.27, M.
02 01 41 32 30 31 31 2F 30 38 2F 30 34 2C 31 37 3A 30 33 3A 32 38 2C 2B
30 30 31 2E 32 39 2C 46 2C 32 30 31 31 2F 30 38 2F 30 34 2C 31 37 3A 30
33 3A 30 32 2C 2B 30 30 31 2E 32 35 2C 46 2C 32 30 31 31 2F 30 38 2F 30
34 2C 31 37 3A 30 32 3A 32 30 2C 2B 30 30 30 2E 37 31 2C 46 2C 32 30 31
31 2F 30 38 2F 30 34 2C 31 37 3A 30 32 3A 30 30 2C 2B 30 30 31 2E 32 37
2C 4D 03 62 0D 0A
BSEp1_p2_p3_p4_p5_p6_p7: Measurement Setup
Set the delay, integral period, repeat, and logger setup.
Instructi
on
P1
P2
P3
P4
P5
P6
P7
Explanat
ion
BSE
p1: delay;
1~60=1~6
0s;
61=Sync.
1m;
62=Sync.
15m;
63=Sync.
30m;
64=Sync.
1h;
Default: 1
p2:
integral
period;
0=Inf;
1~59=1~5
9s;
60~118=1
~59m;
119~142=
1h~24h;
Default: 0
p3:
repeat;
0=Inf;
1~9999
=1~9999
times;
Default: 0
p4: SWN
logger;
0=disable
;
1=enable;
Default: 0
p5:SWN
logger ;st
ep
0=0.1s;
1=0.2s;
2=0.5s;
3~61=1~5
9s;
62~120=1
~59m;
121~144=
1h~24h;
Default: 3
p6:CSD
logger;
0=disable
;
1=enable;
Default: 0
p7:CSD
logger
step;
0~58=1~5
9s;
59~117=1
~59m;
118~141=
1~24h;
Default:
59
ASCII
B
S
E
1
0
0
0
3
0
59
