BSE?: Query Measurement Setup
Instruction
Parameters
Explanation
BSE
Query parameter: ?
ASCII
B
S
E
?
Hex
42H
53H
45H
3FH
Byte
1
1
1
1
Return
Return parameter of measurement setup: delay, integral period,
repeat, SWN logger, SWN logger step, CSD Logger, CSD Logger step.
Example: query the measurement setup.
02 01 43 42 53 45 3F 03 28 0D 0A
Returns: the current measurement setup: delay=2s, integral period=5min, repeat=infinite,
SWN logger=enable, SWN logger step= 0.2s, CSD logger=enable, CSD logger step=2s.
02 01 41 30 32 2C 30 36 34 2C 30 30 30 30 2C 31 2C 30 30 31 2C 31 2C 30
30 31 03 71 0D 0A
RNS?: Query Measurement Range
Instruction
Parameters
Explanation
RNG
Query parameter: ?
ASCII
R
N
S
?
Hex
52H
4EH
53H
3FH
Byte
1
1
1
1
Return
Return measurement range
Example: query measurement range.
02 01 43 52 4E 53 3F 03 33 0D 0A
Return: linearity, dynamic and peak C range is 22.8-133.8, 12.8-133.8, 44.8-136.8.
