BSWA 308/309 BSWA Technology Co., Ltd
80
Byte
1
1
1
1
1
1
1
1
Return
ACK / NAK
Example: enable 3Profile, statistical, time history, custom, GPS.
02 01 43 45 54 46 31 20 31 20 31 20 31 20 31 03 25 0D 0A
Return: ACK
02 01 06 03 06 0D 0A
ETF?: Query Extended Function Setting
Instruction
Parameters
Explanation
ETF
Query parameter: ?
ASCII
E
T
F
?
Hex
45H
54H
46H
3FH
Byte
1
1
1
1
Return
Return the extended function setting
Example: query the extended function setting
02 01 43 45 54 46 3F 03 2B 0D 0A
Return: 3Profile, statistical, time history, custom and GPS are all enable
02 01 41 31 2C 31 2C 31 2C 31 2C 31 03 70 0D 0A
STSp1_p2_p3……p11_p12: Set Statistical
Instruction
P1
P2
P3~P12
Explanation
STS
p1: Filter
0=A;
1=B;
2=C;
3=Z;
Default: 0
p2: Detector
0=F;
1=S;
2=I;
Default: 0
p3~p12: statistical percentage;
Range: 1~99;
Default: 10, 20, 30, 40, 50, 60,
70, 80, 90, 99
ASCII
S
T
S
0
0
10_20_30_40_50_
60_70_80_90_99
Hex
53H
54H
53H
30H
30H
31H, 30H, 20H, 32H, 30H, 20H,
33H, 30H, 20H, 34H, 30H, 20H,
35H, 30H, 20H, 35H, 30H, 20H,
36H, 30H, 20H, 37H, 30H, 20H,
38H, 30H, 20H, 39H, 30H, 20H,
39H, 39H
Byte
1
1
1
1
1
10~20+9 (spaces)
Return
ACK / NAK
