Example: set filter as B, detector as I, percentage as 10, 20, 30, 40, 50, 60, 70, 80, 90 and 99.
02 01 43 53 54 53 31 20 32 20 31 30 20 32 30 20 33 30 20 34 30 20 35 30 20 36 30
20 37 30 20 38 30 20 39 30 20 39 39 03 35 0D 0A
Return: ACK.
02 01 06 03 06 0D 0A
STS?: Query Statistical
Instruction
Parameters
Explanation
STS
Query parameter: ?
ASCII
S
T
S
?
Hex
53H
54H
53H
3FH
Byte
1
1
1
1
Return
Return filter, detector and 10 percentage of statistical
Example: query statistical
02 01 43 53 54 53 3F 03 28 0D 0A
Return: filter=B, detector=I, percentage=10, 20, 30, 40, 50, 60, 70, 80, 90, 99.
02 01 41 31 2C 32 2C 31 30 2C 32 30 2C 33 30 2C 34 30 2C 35 30 2C 36 30
2C 37 30 2C 38 30 2C 39 30 2C 39 39 03 6F 0D 0A
HISp1_p2: Set Time History
Instruction
Parameters 1
Parameters 2
Explanation
HIS
p1: Profile;
0=Profile1;
1=Profile2;
2=Profile3;
Default: 1
p2: Duration;
0=1min;
1=2min;
2=10min;
Default: 1
ASCII
H
I
S
1
1
Hex
48H
49H
53H
31H
31H
Byte
1
1
1
1
1
Return
ACK / NAK
Example: set Profile2 as data sources and duration as 2min.
02 01 43 48 49 53 31 20 31 03 31 0D 0A
Return: ACK.
02 01 06 03 06 0D 0A
